| Production |
| Manufacturer: | J.I. Case
|
| Type: | Row-Crop tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Original price: | $30,000 (1978 )
|
| J.I. Case 1270 Power |
| Drawbar (claimed): | 109 hp
81.3 kW
|
| PTO (claimed): | 127 hp
94.7 kW
|
| Drawbar (tested): | 116.77 hp
87.1 kW
|
| PTO (tested): | 135.39 hp
101.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | power
|
| Brakes: | differential hydraulic wet disc
|
| Cab: | Cab standard
|
| Transmission: | 12-speed partial power shift
|
| Photos |
| | J.I. Case 1270 photos... |
| Hydraulics |
| Pressure: | 2000 psi
137.9 bar
|
| Valves: | 2
|
| Pump flow: | 20 gpm
75.7 lpm
|
| Total flow: | 28 gpm
106.0 lpm
|
| | 48 gpm
181.7 lpm *Optional
|
| Steering flow: | 8 gpm
30.3 lpm
|
| Tractor hitch |
| Rear Type: | III/II
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000
|
| Dimensions & Tires |
| Wheelbase: | 104 inches
264 cm
|
| Weight: | 13,400 lbs
6078 kg
|
| Front tire: | 10.00-16
|
| Rear tire: | 18.4-38
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Batteries: | 2
|
| Battery CCA: | 300
|
| Battery volts: | 12
|
| Battery Group: | 30H
|
|
