| Production |
| Manufacturer: | J.I. Case
|
| Type: | Utility tractor
|
| Factory: | Meltham Mills, Huddersfield, England
|
| Original price: | $21,200 (1984)
|
| J.I. Case 1294 Power |
| Engine: | 62 hp
46.2 kW
|
| PTO (claimed): | 56 hp
41.8 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Differential lock: | standard
|
| Steering: | hydrostatic power
|
| Brakes: | drum
|
| Cab: | Cab standard.
|
| Transmission: | 12-speed synchromesh
|
| Hydraulics |
| Type: | open
|
| Pressure: | 2460 psi
169.6 bar
|
| Valves: | 1 to 3
|
| Pump flow: | 7.1 gpm
26.9 lpm
|
| Steering flow: | 7.7 gpm
29.1 lpm
|
| Tractor hitch |
| Rear Type: | II/I
|
| Rear lift (at 24"/610mm): | 2,970 lbs
1347 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 83 inches
210 cm (2WD)
|
| | 84.25 inches
213 cm (4WD)
|
| Weight: | 6320 to 7000 pounds
|
| Front tire: | 7.50-16
|
| Rear tire: | 13.6-38
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 45
|
| Battery CCA: | 420
|
| | 550 (heavy-duty)
|
| Battery volts: | 12
|
| Battery AH: | 96
|
| | 128 (heavy-duty)
|
|
