| Production |
| Manufacturer: | J.I. Case
|
| Type: | Utility tractor
|
| Factory: | Meltham Mills, Huddersfield, England
|
| Original price: | $22,100 (1983)
|
| J.I. Case 1390 Power |
| PTO (claimed): | 60 hp
44.7 kW
|
| Drawbar (tested): | 50.26 hp
37.5 kW
|
| PTO (tested): | 60.59 hp
45.2 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | mechanical drum
|
| Cab: | Two-post ROPS. Cab optional.
|
| Transmission: | 12-speed synchromesh
|
| Capacity |
| Fuel: | 19 gal
71.9 L
|
| Hydraulic system: | 7.1 gal
26.9 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 7.1 gal
26.9 L
|
| Valves: | 1 or 2
|
| Pump flow: | 15.3 gpm
57.9 lpm
|
| Tractor hitch |
| Rear Type: | 2/1
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 84 inches
213 cm
|
| Weight: | 5,500 lbs
2494 kg
|
| Front tire: | 7.50-16
|
| Rear tire: | 16.9-30
|
| 1390 Serial Numbers |
| Location: | Serial number stamped into the top of the tractor's frame on the right side, next to the engine.
|
| 1980: | 11120101
|
| 1981: | 11122928
|
| 1982: | 11126132
|
| 1983: | 11130040
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 26
|
| Battery volts: | 12
|
|
