Case 1490 Tractors

Case 1490
Power: 83 hp
Date of manufacture :
1980 - 1983
Production
Manufacturer:J.I. Case
Type:Utility tractor
Factory:Meltham Mills, Huddersfield, England
Original price:$25,400 (1983 )
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:hydraulic wet disc
Cab:Two-post ROPS. Cab optional.
Transmissions:12-speed synchromesh
 12-speed partial power shift
Photos
J.I. Case 1490 photos...
Hydraulics
Type:open center
Pressure:2000 psi
137.9 bar
Valves:1
Total flow:8.4 gpm
31.8 lpm
Tractor hitch
Rear Type:II
Rear lift:4,400 lbs
1995 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:88.5 inches
224 cm
Weight:6490 to 7580 pounds
Front tire:11L-15
Rear tire:18.4-34
1490 Serial Numbers
Location:Serial number stamped into the top of the tractor's frame on the right side, next to the engine.
1980:11180101
1981:11182782
1982:11185693
1983:11188540

how to read serial numbers...

Electrical
Ground:negative
Battery volts:12
