| Production |
| Manufacturer: | J.I. Case
|
| Type: | Utility tractor
|
| Factory: | Meltham Mills, Huddersfield, England
|
| Original price: | $30,000 (1983 )
|
| J.I. Case 1690 Power |
| PTO (claimed): | 90 hp
67.1 kW
|
| Drawbar (tested): | 72.55 hp
54.1 kW
|
| PTO (tested): | 90.39 hp
67.4 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Two-post ROPS. Cab optional.
|
| Transmissions: | 12-speed synchromesh
|
| | 12-speed partial power shift
|
| Photos |
| | J.I. Case 1690 photos... |
| Hydraulics |
| Type: | open center
|
| Pump flow: | 20 gpm
75.7 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 100.5 inches
255 cm
|
| Weight: | 8755 lbs
3971 kg
|
| Front tire: | 10.00-16
|
| Rear tire: | 18.4-34
|
| 1690 Serial Numbers |
| Location: | Serial number stamped into the top of the tractor's frame on the right side, next to the engine.
|
photo of 1690 serial number
| | 1980: | 11120101
|
| 1981: | 11211841
|
| 1982: | 11213684
|
| 1983: | 11214373
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
|
