| Production |
| Manufacturer: | CaseIH
|
| Type: | Row-Crop tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Original price: | $141,000
|
| CaseIH MX270 Power |
| PTO (claimed): | 235 hp
175.2 kW
|
| Drawbar (tested): | 207.01 hp
154.4 kW
|
| PTO (tested): | 270.93 hp
202.0 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic wet disc
|
| Cab: | Cab standard
|
| Transmissions: | 18-speed full power shift
|
| | 24-speed
|
| Photos |
| | CaseIH MX270 photos... |
| Capacity |
| Fuel: | 160 gal
605.6 L
|
| Hydraulic system: | 45.5 gal
172.2 L
|
| Hydraulics |
| Type: | PFC
|
| Capacity: | 45.5 gal
172.2 L
|
| Valves: | 3
|
| Pump flow: | 30 gpm
113.6 lpm
|
| Tractor hitch |
| Rear Type: | III
|
| Rear lift: | 14,500 lbs
6577 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000 (1.75)
|
| Engine RPM: | 1000@1974
|
| Dimensions & Tires |
| Wheelbase: | 118.3 inches
300 cm
|
| Weight: | 20,900 lbs
9480 kg
|
| Front tire: | 14.9R34
|
| Rear tire: | 18.4R46
|
| Full dimensions and tires ... |
| MX270 Serial Numbers |
| 1999: | JJA0097438
|
| 2000: | JJA0105000
|
| 2001: | JJA0108800
|
| 2002: | JJA0115301
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Battery volts: | 12
|
|
