Minneapolis-Moline 335 Tractors
 |
|
Power: 35 hp[P]
Date of manufacture : 1956 - 1961 |
| Production |
| Manufacturer: | Minneapolis-Moline
|
| Total built: | 2,500 (utility)
|
| | 334 (industrial)
|
| | 750 (Universal)
|
| Original price: | $2500 (1961)
|
| Minneapolis-Moline 335 Power |
| Drawbar (claimed): | 24 hp
17.9 kW
|
| PTO (claimed): | 32 hp
23.9 kW
|
| Drawbar (tested): | 29.84 hp
22.3 kW
|
| Belt (tested): | 33.50 hp
25.0 kW
|
| Minneapolis-Moline 335 Engine |
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | power assist
|
| Brakes: | mechanical dry disc
|
| Cab: | Open operator station.
|
| Transmissions: | 5-speed unsynchronized gear
|
| | 10-speed partial power shift
|
| Photos |
| | Minneapolis-Moline 335 photos... |
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 79 inches
200 cm
|
| Weight: | 3,650 lbs
1655 kg
|
| Front tire: | 5.50-16
|
| Rear tire: | 12-24
|
| Full dimensions and tires ... |
| 335 Serial Numbers |
| Location: | Right side of tractor frame.
|
photo of 335 serial number
| | 1956: | A1P 10400001 (utility)
|
| 1957: | A1P 10400102 (utility)
|
| 1958: | A1P 10402088 (utility)
|
| 1959: | A1P 10402337 (utility)
|
| 1960: | A1P 10402490 (utility)
|
| 1961: | A1P 10402490 (utility)
|
| 1957: | A1W 11300001 (industrial)
|
| 1958: | A1W 11300441 (industrial)
|
| 1959: | A1W 11300522 (industrial)
|
| 1960: | A1W 11300597 (industrial)
|
| 1957: | A1 11600001 (universal)
|
| 1958: | A1 11600302 (universal)
|
| 1959: | A1 11600306 (universal)
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 8.375 inches
21 cm
|
| Width: | 6.5 inches
16 cm
|
| RPM: | 1516
|
| Speed: | 3323 ft/min
1012.85 meters/min
|
|
